OrCAD X Capture How to Series Part 6 - Finishing Touches, Netlisting & Exporting the Design
Welcome to the OrCAD X Capture Tutorial Series with Adam Fuchs. In this series Adam will demonstrate how to create a complete schematic in a step-by-step process. In this video, Adam will demonstrate the final steps of schematic design, including how to export your design and netlisting for use with a PCB Editor.
Click here to access the design files to follow along with Adam.
Disclaimer: This video may have been recorded prior to changes made to the product’s user interface, or the video may be based on an earlier release of the product. The concepts and workflows conveyed in this video still apply to the current release of the product.
