Allegro Design Entry Capture

CadenceĀ® schematic capture technology offers a comprehensive solution for entering, modifying, and verifying complex system designs quickly and cost-effectively.

Download PDF

To develop innovate products in narrow market windows, system designers face far greater challenges than simply capturing connectivity using schematics and sending designs into layout. They must use optimal library parts, reuse sections of previous designs to reduce risk and shorten development time, add constraints early to eliminate iterations, and perform simulation and signal integrity analysis to ensure desired operation. Cadence® schematic capture technology offers a comprehensive solution for entering, modifying, and verifying complex system designs quickly and cost-effectively.
