How to Design a Custom Keyboard PCB

Learn how to design a custom keyboard from scratch with this step-by-step tutorial. This video series will cover in-depth details on schematic design, PCB layout, and making key decisions to bring this project to life.

Access Your Design Files

Submit the form and your download will begin instantly.

Designing the PCB Schematic

Sample content thumbnail

Step 1: Creating a Block Diagram and Choosing the Right Microcontroller

In step 1 of our keyboard PCB design series, we’ll walk through high-level schematic planning using OrCAD X as our design tool. Adam will guide you through the block diagram of the project explaining

Sample content thumbnail

Step 2: Designing a Mechanical Keyboard PCB with a Raspberry Pi Microcontroller

In step 2 of our custom keyboard PCB design series, we focus on designing the microcontroller section of the schematic using OrCAD X. Adam walks through the process of integrating the Raspberry Pi RP2

Sample content thumbnail

Step 3: Designing the Power Stage for a Reliable Mechanical Keyboard PCB

In step 3 of the schematic portion of designing a custom keyboard PCB from scratch with OrCAD X, Adam walks through the process of integrating a USB-C connector into the design. This part focuses on p

Sample content thumbnail

Step 4: Building the Key Matrix for Your Mechanical Keyboard PCB

In step 4 of the schematic portion on designing a custom keyboard PCB from scratch with OrCAD X, Adam focuses on building the key matrix, the fundamental circuit that detects key presses in mechanica

Sample content thumbnail

Step 5: Enhancing Your Keyboard Design with Custom LED Circuits

In step 5 of the schematic portion on designing a custom keyboard PCB from scratch with OrCAD X, Adam shows you how to integrate custom lighting into your design by building a dedicated LED circuit. T

Sample content thumbnail

Step 6: Designing the LCD Interface for Your Mechanical Keyboard PCB

Welcome to the last video in the schematic portion for designing a custom keyboard PCB from scratch with OrCAD X, Adam demonstrates how to integrate a liquid crystal display (LCD) module into your key

Creating the PCB Layout

Sample content thumbnail

Step 1: Translating the Schematic into a PCB Layout for a Mechanical Keyboard

In the first video of the PCB layout portion for designing a custom keyboard PCB from scratch with OrCAD X, Adam goes step by step through translating the schematic to the PCB layout. From making mino

Sample content thumbnail

Step 2: Drawing the Board Outline for Your Mechanical Keyboard PCB

In step 2 of the PCB layout portion on designing a custom keyboard PCB from scratch with OrCAD X, Adam guides you through the process of creating a keyboard design with detailed dimensions and specifi

Sample content thumbnail

Step 3: Setting Up a Cross Section and Assigning Layer Colors

In step 3 of the PCB layout portion on designing a custom keyboard PCB from scratch with OrCAD X, we’ll guide you through setting up the cross section for your PCB design and customizing its layer col

Sample content thumbnail

Step 4: Placing Components on Your Mechanical Keyboard PCB

In step 4 of the PCB layout portion on designing a custom keyboard PCB from scratch with OrCAD X, we’ll help you efficiently place components on a keyboard PCB using OrCAD X.

Sample content thumbnail

Step 5: Defining Constraints for Your Mechanical Keyboard PCB

In step 5 of the PCB layout portion on designing a custom keyboard PCB from scratch with OrCAD X, Adam teaches you how to set up physical and electrical constraints in OrCAD X to avoid unexpected surp

Sample content thumbnail

Step 6: Completing the Layout for Your Mechanical Keyboard PCB

In step 6 of the PCB layout portion on designing a custom keyboard PCB from scratch with OrCAD X, learn how to route nets efficiently using both assisted and manual route commands. Adam demonstrates w
